fix(subgraph): validate URL hash and redirect to root when subgraph missing (#12169)

*PR Created by the Glary-Bot Agent*

---

## Summary

Fix FE-559: browser forward/back to a deleted subgraph used to leave the
canvas on stale state (and sometimes triggered unrelated tab navigation)
because the subgraph id in the URL hash was looked up with no validation
or fallback.

## Changes

- **What**:
- Added `src/schemas/subgraphIdSchema.ts` — `zSubgraphId =
z.string().uuid()` + `isValidSubgraphId(value)` type guard, matching how
subgraph ids are persisted in `workflowSchema.ts` and generated by
`createUuidv4()`.
- `subgraphNavigationStore.navigateToHash()` now (a) validates the hash
with `isValidSubgraphId` before any lookup, (b) redirects to the root
graph (`router.replace('#' + root.id)` + `canvas.setGraph(root)`) when
the locator is malformed, missing from `root.subgraphs`, or still
unresolved after a workflow-load attempt.
- Replaced the `console.error('subgraph poofed after load?')` dead-end
with the same redirect helper.
- Re-ordered the "already on this graph" short-circuit so a stale canvas
reference to a now-deleted subgraph doesn't suppress the redirect.

## Review Focus

- TDD: 6 new tests in `subgraphNavigationStore.navigateToHash.test.ts`
cover valid navigation, deleted-subgraph hash, malformed (non-UUID)
hash, no-op when target equals current, empty-hash root case, and
stale-canvas recovery. 15 new tests in `subgraphIdSchema.test.ts` lock
down the validator.
- `redirectToRoot()` toggles `blockHashUpdate` while calling
`router.replace`, so the new redirect doesn't re-trigger `updateHash()`
and clobber the canvas state.
- Generalized validation: the new schema lives in `src/schemas/` and can
be reused anywhere a subgraph id crosses an untrusted boundary (URL,
IPC, etc.).

## Manual Verification

Ran ComfyUI backend (`--cpu --port 8188`) + frontend dev server, then
drove Playwright through three scenarios:

| Input hash | Result | Console |
|---|---|---|
| `#11111111-2222-4333-8444-555555555555` (UUID-shaped, non-existent) |
URL replaced with `#<root-id>` | `[subgraphNavigation] subgraph not
found: 11111111-…; redirecting to root graph` |
| `#not-a-valid-uuid` (malformed) | URL replaced with `#<root-id>` |
`[subgraphNavigation] invalid subgraph id in hash: not-a-valid-uuid;
redirecting to root graph` |
| `#aaaaaaaa-bbbb-4ccc-8ddd-eeeeeeeeeeee` (UUID-shaped, non-existent) |
URL replaced with `#<root-id>` | (same redirect message) |

Screenshot below shows the redirected viewport.

Fixes FE-559

## Screenshots

![ComfyUI canvas after a hash referencing a deleted subgraph was
rewritten to the root graph
hash](https://pub-1fd11710d4c8405b948c9edc4287a3f2.r2.dev/sessions/fe7f8846b3efdc95461cd63995dd10808073dd86c561eff9d8816742eb892687/pr-images/1778562546959-43f5ead4-3e13-45de-a0ac-988c3424368b.png)

┆Issue is synchronized with this [Notion
page](https://www.notion.so/PR-12169-fix-subgraph-validate-URL-hash-and-redirect-to-root-when-subgraph-missing-35e6d73d3650819f840af1475b9f44d4)
by [Unito](https://www.unito.io)

---------

Co-authored-by: Glary-Bot <glary-bot@users.noreply.github.com>
Co-authored-by: jaeone94 <89377375+jaeone94@users.noreply.github.com>

browser_tests/tests/subgraph/subgraphHashValidation.spec.ts

@@ -0,0 +1,87 @@
+import type { Page } from '@playwright/test'
+import { expect } from '@playwright/test'
+
+import { comfyPageFixture as test } from '@e2e/fixtures/ComfyPage'
+
+async function waitForRootCanvasReady(page: Page) {
+  await expect
+    .poll(async () => {
+      const state = await page.evaluate(() => ({
+        rootId: window.app?.rootGraph?.id ?? '',
+        canvasGraphId: window.app?.canvas?.graph?.id ?? ''
+      }))
+      return state.rootId !== '' && state.canvasGraphId === state.rootId
+    })
+    .toBe(true)
+}
+
+async function expectCanvasOnRootGraph(page: Page) {
+  await expect
+    .poll(async () =>
+      page.evaluate(() => ({
+        rootId: window.app!.rootGraph.id,
+        canvasGraphId: window.app!.canvas.graph?.id,
+        hash: window.location.hash
+      }))
+    )
+    .toEqual({
+      rootId: expect.any(String),
+      canvasGraphId: expect.stringMatching(/.+/),
+      hash: expect.stringMatching(/^#.+/)
+    })
+  const state = await page.evaluate(() => ({
+    rootId: window.app!.rootGraph.id,
+    canvasGraphId: window.app!.canvas.graph?.id,
+    hash: window.location.hash
+  }))
+  expect(state.canvasGraphId).toBe(state.rootId)
+  expect(state.hash).toBe(`#${state.rootId}`)
+}
+
+test.describe(
+  'Subgraph hash validation (FE-559)',
+  { tag: ['@subgraph'] },
+  () => {
+    test('redirects URL and canvas to root for a non-existent subgraph hash', async ({
+      comfyPage
+    }) => {
+      await waitForRootCanvasReady(comfyPage.page)
+      const rootId = await comfyPage.page.evaluate(
+        () => window.app!.rootGraph.id
+      )
+      const phantomId = '11111111-1111-4111-8111-111111111111'
+      expect(phantomId).not.toBe(rootId)
+
+      await comfyPage.page.evaluate((hash) => {
+        window.location.hash = hash
+      }, `#${phantomId}`)
+
+      await expect
+        .poll(() => comfyPage.page.evaluate(() => window.location.hash), {
+          timeout: 5000
+        })
+        .toBe(`#${rootId}`)
+      await expectCanvasOnRootGraph(comfyPage.page)
+    })
+
+    test('redirects URL and canvas to root when hash is malformed', async ({
+      comfyPage
+    }) => {
+      await waitForRootCanvasReady(comfyPage.page)
+      const rootId = await comfyPage.page.evaluate(
+        () => window.app!.rootGraph.id
+      )
+
+      await comfyPage.page.evaluate(() => {
+        window.location.hash = '#not-a-valid-uuid'
+      })
+
+      await expect
+        .poll(() => comfyPage.page.evaluate(() => window.location.hash), {
+          timeout: 5000
+        })
+        .toBe(`#${rootId}`)
+      await expectCanvasOnRootGraph(comfyPage.page)
+    })
+  }
+)

knip.config.ts

@@ -43,7 +43,6 @@ const config: KnipConfig = {
     '@iconify/json',
     '@primeuix/forms',
     '@primeuix/styled',
-    '@primeuix/utils',
     '@primevue/icons'
   ],
   ignore: [

packages/design-system/src/css/style.css

@@ -1892,3 +1892,17 @@ audio.comfy-audio.empty-audio-widget {
     300% 14px;
   background-attachment: local, local, scroll, scroll;
 }
+
+/*
+  PrimeVue overlays teleport to body. When a Reka modal dialog is open it sets
+  body { pointer-events: none } via DismissableLayer, which propagates to the
+  body-portaled overlays and makes them unclickable. PrimeVue's own Dialog
+  sets pointer-events inline, but Select / ColorPicker / Popover / Autocomplete
+  overlays do not, so they need to opt in here.
+*/
+.p-select-overlay,
+.p-colorpicker-panel,
+.p-popover,
+.p-autocomplete-overlay {
+  pointer-events: auto;
+}

src/components/dialog/GlobalDialog.test.ts

@@ -8,6 +8,10 @@ import { defineComponent, h } from 'vue'
 import { createI18n } from 'vue-i18n'

 import GlobalDialog from '@/components/dialog/GlobalDialog.vue'
+import {
+  onRekaFocusOutside,
+  onRekaPointerDownOutside
+} from '@/components/dialog/rekaPrimeVueBridge'
 import { useDialogStore } from '@/stores/dialogStore'

 const i18n = createI18n({
@@ -190,3 +194,88 @@ describe('GlobalDialog Reka parity with PrimeVue', () => {
     expect(store.isDialogOpen('reka-esc-blocked')).toBe(true)
   })
 })
+
+describe('shouldPreventRekaDismiss', () => {
+  function makeEvent(target: Element | null) {
+    let prevented = false
+    return {
+      detail: { originalEvent: { target } },
+      preventDefault: () => {
+        prevented = true
+      },
+      get defaultPrevented() {
+        return prevented
+      }
+    } as unknown as CustomEvent<{ originalEvent: PointerEvent }> & {
+      defaultPrevented: boolean
+    }
+  }
+
+  it.for([
+    'p-select-overlay',
+    'p-colorpicker-panel',
+    'p-popover',
+    'p-autocomplete-overlay',
+    'p-overlay-mask',
+    'p-dialog'
+  ])('prevents dismiss when target is inside %s', (className) => {
+    const overlay = document.createElement('div')
+    overlay.className = className
+    const inner = document.createElement('button')
+    overlay.appendChild(inner)
+    document.body.appendChild(overlay)
+
+    const event = makeEvent(inner)
+    onRekaPointerDownOutside({ dismissableMask: undefined }, event)
+
+    expect(event.defaultPrevented).toBe(true)
+    overlay.remove()
+  })
+
+  it('allows dismiss when target is outside any PrimeVue overlay', () => {
+    const event = makeEvent(document.body)
+    onRekaPointerDownOutside({ dismissableMask: undefined }, event)
+    expect(event.defaultPrevented).toBe(false)
+  })
+
+  it('prevents dismiss when dismissableMask is false even outside an overlay', () => {
+    const event = makeEvent(document.body)
+    onRekaPointerDownOutside({ dismissableMask: false }, event)
+    expect(event.defaultPrevented).toBe(true)
+  })
+
+  it.for(['p-dialog', 'p-select-overlay'])(
+    'focus-outside on a sibling %s portal does not dismiss the parent',
+    (className) => {
+      const overlay = document.createElement('div')
+      overlay.className = className
+      const inner = document.createElement('button')
+      overlay.appendChild(inner)
+      document.body.appendChild(overlay)
+
+      const event = makeEvent(inner)
+      onRekaFocusOutside(event)
+
+      expect(event.defaultPrevented).toBe(true)
+      overlay.remove()
+    }
+  )
+
+  it('focus-outside still dismisses when focus moves to a non-portal element', () => {
+    const event = makeEvent(document.body)
+    onRekaFocusOutside(event)
+    expect(event.defaultPrevented).toBe(false)
+  })
+
+  it('focus-outside on a sibling Reka portal does not dismiss the parent', () => {
+    const portal = document.createElement('div')
+    portal.setAttribute('role', 'dialog')
+    document.body.appendChild(portal)
+
+    const event = makeEvent(portal)
+    onRekaFocusOutside(event)
+
+    expect(event.defaultPrevented).toBe(true)
+    portal.remove()
+  })
+})

src/components/dialog/GlobalDialog.vue

@@ -8,9 +8,14 @@
       @update:open="(open) => onRekaOpenChange(item.key, open)"
     >
       <DialogPortal>
-        <DialogOverlay />
+        <DialogOverlay
+          v-reka-z-index
+          :class="item.dialogComponentProps.overlayClass"
+        />
         <DialogContent
+          v-reka-z-index
           :size="item.dialogComponentProps.size ?? 'md'"
+          :maximized="!!item.dialogComponentProps.maximized"
           :class="item.dialogComponentProps.contentClass"
           :aria-labelledby="item.key"
           @escape-key-down="
@@ -19,34 +24,51 @@
               e.preventDefault()
           "
           @pointer-down-outside="
-            (e) =>
-              item.dialogComponentProps.dismissableMask === false &&
-              e.preventDefault()
+            (e) => onRekaPointerDownOutside(item.dialogComponentProps, e)
           "
+          @focus-outside="onRekaFocusOutside"
           @mousedown="() => dialogStore.riseDialog({ key: item.key })"
         >
-          <DialogHeader v-if="!item.dialogComponentProps.headless">
-            <component
-              :is="item.headerComponent"
-              v-if="item.headerComponent"
-              v-bind="item.headerProps"
-              :id="item.key"
-            />
-            <DialogTitle v-else :id="item.key">
-              {{ item.title || ' ' }}
-            </DialogTitle>
-            <DialogClose v-if="item.dialogComponentProps.closable !== false" />
-          </DialogHeader>
-          <div class="flex-1 overflow-auto px-4 py-2">
+          <template v-if="item.dialogComponentProps.headless">
             <component
               :is="item.component"
               v-bind="item.contentProps"
               :maximized="item.dialogComponentProps.maximized"
             />
-          </div>
-          <DialogFooter v-if="item.footerComponent">
-            <component :is="item.footerComponent" v-bind="item.footerProps" />
-          </DialogFooter>
+          </template>
+          <template v-else>
+            <DialogHeader>
+              <component
+                :is="item.headerComponent"
+                v-if="item.headerComponent"
+                v-bind="item.headerProps"
+                :id="item.key"
+              />
+              <DialogTitle v-else :id="item.key">
+                {{ item.title || ' ' }}
+              </DialogTitle>
+              <div class="flex items-center gap-1">
+                <DialogMaximize
+                  v-if="item.dialogComponentProps.maximizable"
+                  :maximized="!!item.dialogComponentProps.maximized"
+                  @toggle="toggleMaximize(item)"
+                />
+                <DialogClose
+                  v-if="item.dialogComponentProps.closable !== false"
+                />
+              </div>
+            </DialogHeader>
+            <div class="flex-1 overflow-auto px-4 py-2">
+              <component
+                :is="item.component"
+                v-bind="item.contentProps"
+                :maximized="item.dialogComponentProps.maximized"
+              />
+            </div>
+            <DialogFooter v-if="item.footerComponent">
+              <component :is="item.footerComponent" v-bind="item.footerProps" />
+            </DialogFooter>
+          </template>
         </DialogContent>
       </DialogPortal>
     </Dialog>
@@ -55,7 +77,6 @@
       v-model:visible="item.visible"
       class="global-dialog"
       v-bind="item.dialogComponentProps"
-      :pt="getDialogPt(item)"
       :aria-labelledby="item.key"
     >
       <template #header>
@@ -86,29 +107,25 @@
 </template>

 <script setup lang="ts">
-import { merge } from 'es-toolkit/compat'
 import PrimeDialog from 'primevue/dialog'
-import type { DialogPassThroughOptions } from 'primevue/dialog'
-import { computed } from 'vue'

 import Dialog from '@/components/ui/dialog/Dialog.vue'
 import DialogClose from '@/components/ui/dialog/DialogClose.vue'
 import DialogContent from '@/components/ui/dialog/DialogContent.vue'
 import DialogFooter from '@/components/ui/dialog/DialogFooter.vue'
 import DialogHeader from '@/components/ui/dialog/DialogHeader.vue'
+import DialogMaximize from '@/components/ui/dialog/DialogMaximize.vue'
 import DialogOverlay from '@/components/ui/dialog/DialogOverlay.vue'
 import DialogPortal from '@/components/ui/dialog/DialogPortal.vue'
 import DialogTitle from '@/components/ui/dialog/DialogTitle.vue'
-import { useFeatureFlags } from '@/composables/useFeatureFlags'
-import { isCloud } from '@/platform/distribution/types'
-import type { DialogComponentProps, DialogInstance } from '@/stores/dialogStore'
+import {
+  onRekaFocusOutside,
+  onRekaPointerDownOutside
+} from '@/components/dialog/rekaPrimeVueBridge'
+import { vRekaZIndex } from '@/components/dialog/vRekaZIndex'
+import type { DialogInstance } from '@/stores/dialogStore'
 import { useDialogStore } from '@/stores/dialogStore'

-const { flags } = useFeatureFlags()
-const teamWorkspacesEnabled = computed(
-  () => isCloud && flags.teamWorkspacesEnabled
-)
-
 const dialogStore = useDialogStore()

 function isRekaItem(item: DialogInstance) {
@@ -119,20 +136,8 @@ function onRekaOpenChange(key: string, open: boolean) {
   if (!open) dialogStore.closeDialog({ key })
 }

-function getDialogPt(item: {
-  key: string
-  dialogComponentProps: DialogComponentProps
-}): DialogPassThroughOptions {
-  const isWorkspaceSettingsDialog =
-    item.key === 'global-settings' && teamWorkspacesEnabled.value
-  const basePt = item.dialogComponentProps.pt || {}
-
-  if (isWorkspaceSettingsDialog) {
-    return merge(basePt, {
-      mask: { class: 'p-8' }
-    })
-  }
-  return basePt
+function toggleMaximize(item: DialogInstance) {
+  item.dialogComponentProps.maximized = !item.dialogComponentProps.maximized
 }
 </script>

@@ -163,19 +168,6 @@ function getDialogPt(item: {
   }
 }

-/* Workspace mode: wider settings dialog */
-.settings-dialog-workspace {
-  width: 100%;
-  max-width: 1440px;
-  height: 100%;
-}
-
-.settings-dialog-workspace .p-dialog-content {
-  width: 100%;
-  height: 100%;
-  overflow-y: auto;
-}
-
 .manager-dialog {
   height: 80vh;
   max-width: 1724px;

src/components/dialog/content/setting/KeybindingPanel.vue

@@ -244,7 +244,7 @@
       <ContextMenuPortal>
         <ContextMenuContent
           :style="keybindingOverlayContentStyle"
-          class="z-1200 min-w-56 rounded-lg border border-border-subtle bg-base-background px-2 py-3 shadow-interface"
+          class="z-1800 min-w-56 rounded-lg border border-border-subtle bg-base-background px-2 py-3 shadow-interface"
         >
           <ContextMenuItem
             class="flex cursor-pointer items-center gap-2 rounded-sm px-3 py-2 text-sm text-text-primary outline-none select-none hover:bg-node-component-surface-hovered focus:bg-node-component-surface-hovered data-disabled:cursor-default data-disabled:opacity-50"

src/components/dialog/rekaPrimeVueBridge.ts

@@ -0,0 +1,49 @@
+// PrimeVue overlays (Select, ColorPicker, Popover, Autocomplete, stacked
+// PrimeVue Dialogs) teleport to body. Reka treats clicks on body-portaled
+// elements as outside its dialog and would auto-dismiss on the first
+// interaction, tearing the overlay down mid-interaction. Treat any
+// PrimeVue overlay click as inside.
+const PRIMEVUE_OVERLAY_SELECTORS =
+  '.p-select-overlay, .p-colorpicker-panel, .p-popover, .p-autocomplete-overlay, .p-overlay, .p-overlay-mask, .p-dialog'
+
+// Reka portals its own dialogs / popovers / menus into the body too. When a
+// nested Reka layer opens on top of a non-modal parent, the parent's
+// DismissableLayer sees the focus shift / pointer-down as "outside" and would
+// dismiss itself. These selectors cover the portaled roots so we can treat
+// interactions on them as inside.
+const REKA_PORTAL_SELECTORS =
+  '[data-reka-popper-content-wrapper], [data-reka-dialog-content], [data-reka-menu-content], [data-reka-context-menu-content], [role="dialog"], [role="menu"], [role="listbox"], [role="tooltip"]'
+
+const OUTSIDE_LAYER_SELECTORS = `${PRIMEVUE_OVERLAY_SELECTORS}, ${REKA_PORTAL_SELECTORS}`
+
+type OutsideEvent = CustomEvent<{ originalEvent: Event }>
+
+function isInsideOverlay(target: EventTarget | null): boolean {
+  return (
+    target instanceof Element &&
+    target.closest(OUTSIDE_LAYER_SELECTORS) !== null
+  )
+}
+
+export function onRekaPointerDownOutside(
+  options: { dismissableMask?: boolean },
+  event: OutsideEvent
+) {
+  if (isInsideOverlay(event.detail.originalEvent.target)) {
+    event.preventDefault()
+    return
+  }
+  if (options.dismissableMask === false) {
+    event.preventDefault()
+  }
+}
+
+// Focus / interact-outside fires when focus moves to a sibling portal (a
+// nested Reka or PrimeVue dialog teleported to body). Without this guard a
+// non-modal Reka dialog would dismiss itself the moment a nested dialog
+// receives focus.
+export function onRekaFocusOutside(event: OutsideEvent) {
+  if (isInsideOverlay(event.detail.originalEvent.target)) {
+    event.preventDefault()
+  }
+}

src/components/dialog/vRekaZIndex.ts

@@ -0,0 +1,17 @@
+import { ZIndex } from '@primeuix/utils/zindex'
+import type { Directive } from 'vue'
+
+// Both Reka and PrimeVue dialogs can appear at any depth in dialogStack, in
+// any order. PrimeVue auto-increments a per-key z-index counter so later
+// dialogs always cover earlier ones; Reka uses a static z-1700 class which
+// can lose to an already-open PrimeVue dialog. Registering Reka's content
+// element with the same ZIndex counter (key 'modal', base 1700) makes both
+// renderers share one stacking sequence: whichever dialog opens last wins.
+export const vRekaZIndex: Directive<HTMLElement> = {
+  mounted(el) {
+    ZIndex.set('modal', el, 1700)
+  },
+  beforeUnmount(el) {
+    ZIndex.clear(el)
+  }
+}

src/components/ui/dialog/DialogContent.vue

@@ -10,11 +10,13 @@ import { dialogContentVariants } from './dialog.variants'

 const {
   size,
+  maximized = false,
   class: customClass = '',
   ...restProps
 } = defineProps<
   DialogContentProps & {
     size?: DialogContentSize
+    maximized?: boolean
     class?: HTMLAttributes['class']
   }
 >()
@@ -26,7 +28,7 @@ const forwarded = useForwardPropsEmits(restProps, emits)
 <template>
   <DialogContent
     v-bind="forwarded"
-    :class="cn(dialogContentVariants({ size }), customClass)"
+    :class="cn(dialogContentVariants({ size, maximized }), customClass)"
   >
     <slot />
   </DialogContent>

src/components/ui/dialog/DialogMaximize.vue

@@ -0,0 +1,25 @@
+<script setup lang="ts">
+import { useI18n } from 'vue-i18n'
+
+import Button from '@/components/ui/button/Button.vue'
+
+const { maximized = false } = defineProps<{ maximized?: boolean }>()
+const emit = defineEmits<{ toggle: [] }>()
+
+const { t } = useI18n()
+</script>
+
+<template>
+  <Button
+    :aria-label="maximized ? t('g.restoreDialog') : t('g.maximizeDialog')"
+    size="icon"
+    variant="muted-textonly"
+    @click="emit('toggle')"
+  >
+    <i
+      :class="
+        maximized ? 'icon-[lucide--minimize-2]' : 'icon-[lucide--maximize-2]'
+      "
+    />
+  </Button>
+</template>

src/components/ui/dialog/dialog.variants.ts

@@ -2,7 +2,7 @@ import type { VariantProps } from 'cva'
 import { cva } from 'cva'

 export const dialogContentVariants = cva({
-  base: 'fixed top-1/2 left-1/2 z-1700 flex max-h-[85vh] w-[calc(100vw-1rem)] -translate-x-1/2 -translate-y-1/2 flex-col rounded-lg border border-border-subtle bg-base-background shadow-lg outline-none data-[state=closed]:animate-out data-[state=closed]:fade-out-0 data-[state=closed]:zoom-out-95 data-[state=open]:animate-in data-[state=open]:fade-in-0 data-[state=open]:zoom-in-95',
+  base: 'fixed z-1700 flex flex-col rounded-lg border border-border-subtle bg-base-background shadow-lg outline-none data-[state=closed]:animate-out data-[state=closed]:fade-out-0 data-[state=closed]:zoom-out-95 data-[state=open]:animate-in data-[state=open]:fade-in-0 data-[state=open]:zoom-in-95',
   variants: {
     size: {
       sm: 'sm:max-w-sm',
@@ -10,10 +10,15 @@ export const dialogContentVariants = cva({
       lg: 'sm:max-w-3xl',
       xl: 'sm:max-w-5xl',
       full: 'sm:max-w-[calc(100vw-1rem)]'
+    },
+    maximized: {
+      true: 'inset-2 top-2 left-2 size-auto max-h-none max-w-none sm:max-w-none',
+      false: 'top-1/2 left-1/2 max-h-[85vh] w-[calc(100vw-1rem)] -translate-1/2'
     }
   },
   defaultVariants: {
-    size: 'md'
+    size: 'md',
+    maximized: false
   }
 })


src/locales/en/main.json

@@ -138,6 +138,8 @@
     "hideLeftPanel": "Hide left panel",
     "showRightPanel": "Show right panel",
     "hideRightPanel": "Hide right panel",
+    "maximizeDialog": "Maximize dialog",
+    "restoreDialog": "Restore dialog",
     "or": "or",
     "defaultBanner": "default banner",
     "enableOrDisablePack": "Enable or disable pack",

src/main.ts

@@ -107,6 +107,12 @@ app.directive('tooltip', Tooltip)
 app
   .use(router)
   .use(PrimeVue, {
+    zIndex: {
+      modal: 1800,
+      overlay: 1800,
+      menu: 1800,
+      tooltip: 1800
+    },
     theme: {
       preset: ComfyUIPreset,
       options: {

src/platform/assets/mappings/modelNodeMappings.ts

@@ -236,5 +236,8 @@ export const MODEL_NODE_MAPPINGS: ReadonlyArray<
   ['optical_flow', 'OpticalFlowLoader', 'model_name'],

   // ---- WanVideo (ComfyUI-WanVideoWrapper) ----
-  ['loras', 'WanVideoLoraSelect', 'lora']
+  ['loras', 'WanVideoLoraSelect', 'lora'],
+
+  // ---- LTX-Video IC-LoRA (ComfyUI-LTXVideo) ----
+  ['loras', 'LTXICLoRALoaderModelOnly', 'lora_name']
 ] as const satisfies ReadonlyArray<readonly [string, string, string]>

src/platform/settings/composables/useSettingsDialog.test.ts

@@ -0,0 +1,98 @@
+/**
+ * Settings dialog migration regression net: `useSettingsDialog().show()` must
+ * open the Reka-renderer path with sizing that matches the previous
+ * `BaseModalLayout size="sm"` (960px × 80vh). Catches accidental reverts of
+ * the Phase 3 renderer flip.
+ */
+import { beforeEach, describe, expect, it, vi } from 'vitest'
+
+const showDialog = vi.hoisted(() => vi.fn())
+const teamWorkspacesFlag = vi.hoisted(() => ({ value: false }))
+const isCloudRef = vi.hoisted(() => ({ value: false }))
+
+vi.mock('@/stores/dialogStore', () => ({
+  useDialogStore: () => ({ showDialog, closeDialog: vi.fn() })
+}))
+
+vi.mock('@/composables/useFeatureFlags', () => ({
+  useFeatureFlags: () => ({
+    flags: {
+      get teamWorkspacesEnabled() {
+        return teamWorkspacesFlag.value
+      }
+    }
+  })
+}))
+
+vi.mock('@/platform/distribution/types', () => ({
+  get isCloud() {
+    return isCloudRef.value
+  }
+}))
+
+vi.mock('@/i18n', () => ({ t: (k: string) => k }))
+
+vi.mock('@/platform/telemetry', () => ({
+  useTelemetry: () => ({ trackEvent: vi.fn() })
+}))
+
+vi.mock('@/composables/billing/useBillingContext', () => ({
+  useBillingContext: () => ({
+    isActiveSubscription: { value: true },
+    isFreeTier: { value: false },
+    type: { value: 'legacy' }
+  })
+}))
+
+import { useSettingsDialog } from '@/platform/settings/composables/useSettingsDialog'
+
+describe('useSettingsDialog', () => {
+  beforeEach(() => {
+    showDialog.mockReset()
+    teamWorkspacesFlag.value = false
+    isCloudRef.value = false
+  })
+
+  it("show() opens the Reka renderer with size 'full' and 960px content sizing", () => {
+    useSettingsDialog().show()
+    const [args] = showDialog.mock.calls[0]
+    expect(args.key).toBe('global-settings')
+    expect(args.dialogComponentProps.renderer).toBe('reka')
+    expect(args.dialogComponentProps.size).toBe('full')
+    expect(args.dialogComponentProps.contentClass).toContain('max-w-[960px]')
+    expect(args.dialogComponentProps.contentClass).toContain('h-[80vh]')
+  })
+
+  it('show() uses non-modal Reka so nested PrimeVue dialogs keep focus and pointer events', () => {
+    useSettingsDialog().show()
+    const [args] = showDialog.mock.calls[0]
+    expect(args.dialogComponentProps.modal).toBe(false)
+  })
+
+  it('show() omits overlayClass when not in workspace mode', () => {
+    useSettingsDialog().show()
+    const [args] = showDialog.mock.calls[0]
+    expect(args.dialogComponentProps.overlayClass).toBeUndefined()
+  })
+
+  it("show() sets overlayClass 'p-8' when isCloud && teamWorkspacesEnabled", () => {
+    isCloudRef.value = true
+    teamWorkspacesFlag.value = true
+
+    useSettingsDialog().show()
+    const [args] = showDialog.mock.calls[0]
+    expect(args.dialogComponentProps.overlayClass).toBe('p-8')
+  })
+
+  it('show(panel) forwards defaultPanel to the dialog props', () => {
+    useSettingsDialog().show('about')
+    const [args] = showDialog.mock.calls[0]
+    expect(args.props.defaultPanel).toBe('about')
+  })
+
+  it('showAbout() opens the about panel', () => {
+    useSettingsDialog().showAbout()
+    const [args] = showDialog.mock.calls[0]
+    expect(args.props.defaultPanel).toBe('about')
+  })
+})

src/platform/settings/composables/useSettingsDialog.ts

@@ -1,3 +1,5 @@
+import { useFeatureFlags } from '@/composables/useFeatureFlags'
+import { isCloud } from '@/platform/distribution/types'
 import { useDialogService } from '@/services/dialogService'
 import { useDialogStore } from '@/stores/dialogStore'

@@ -6,15 +8,20 @@ import type { SettingPanelType } from '@/platform/settings/types'

 const DIALOG_KEY = 'global-settings'

+const SETTINGS_CONTENT_CLASS =
+  'w-[90vw] max-w-[960px] sm:max-w-[960px] h-[80vh] max-h-none rounded-2xl overflow-hidden'
+
 export function useSettingsDialog() {
   const dialogService = useDialogService()
   const dialogStore = useDialogStore()
+  const { flags } = useFeatureFlags()

   function hide() {
     dialogStore.closeDialog({ key: DIALOG_KEY })
   }

   function show(panel?: SettingPanelType, settingId?: string) {
+    const isWorkspaceMode = isCloud && flags.teamWorkspacesEnabled
     dialogService.showLayoutDialog({
       key: DIALOG_KEY,
       component: SettingDialog,
@@ -22,6 +29,18 @@ export function useSettingsDialog() {
         onClose: hide,
         ...(panel ? { defaultPanel: panel } : {}),
         ...(settingId ? { scrollToSettingId: settingId } : {})
+      },
+      dialogComponentProps: {
+        renderer: 'reka',
+        // Settings hosts nested PrimeVue dialogs (Edit Keybinding, Overwrite
+        // confirm, etc.) that teleport to body. Reka's modal mode traps focus
+        // inside the Settings content and disables body pointer-events, which
+        // breaks those nested dialogs' autofocus and click handling. Non-modal
+        // keeps the visual overlay without those traps.
+        modal: false,
+        size: 'full',
+        contentClass: SETTINGS_CONTENT_CLASS,
+        overlayClass: isWorkspaceMode ? 'p-8' : undefined
       }
     })
   }

src/schemas/subgraphIdSchema.test.ts

@@ -0,0 +1,56 @@
+import { describe, expect, it } from 'vitest'
+
+import { createUuidv4 } from '@/lib/litegraph/src/utils/uuid'
+
+import { isUuidShapedSubgraphId, zSubgraphId } from './subgraphIdSchema'
+
+const CANONICAL_UUID = '550e8400-e29b-41d4-a716-446655440000'
+
+const INVALID_STRING_CASES: Array<[label: string, value: string]> = [
+  ['empty string', ''],
+  ['arbitrary path', '/some/path'],
+  ['plain word', 'subgraph'],
+  ['hash leftover', '#abc'],
+  ['hex but not UUID-shaped', 'abcdef0123456789'],
+  ['UUID with leading hash', `#${CANONICAL_UUID}`],
+  ['UUID with whitespace', ` ${CANONICAL_UUID} `]
+]
+
+const NON_STRING_CASES: Array<[label: string, value: unknown]> = [
+  ['number', 123],
+  ['undefined', undefined],
+  ['null', null],
+  ['object', { id: 'abc' }]
+]
+
+describe('subgraphIdSchema', () => {
+  describe('zSubgraphId', () => {
+    it('accepts a freshly generated UUID v4', () => {
+      expect(zSubgraphId.safeParse(createUuidv4()).success).toBe(true)
+    })
+
+    it('accepts a canonical UUID string', () => {
+      expect(zSubgraphId.safeParse(CANONICAL_UUID).success).toBe(true)
+    })
+
+    it.for(INVALID_STRING_CASES)('rejects %s', ([_label, value]) => {
+      expect(zSubgraphId.safeParse(value).success).toBe(false)
+    })
+
+    it.for(NON_STRING_CASES)('rejects non-string %s', ([_label, value]) => {
+      expect(zSubgraphId.safeParse(value).success).toBe(false)
+    })
+  })
+
+  describe('isUuidShapedSubgraphId', () => {
+    it('returns true for a valid UUID', () => {
+      expect(isUuidShapedSubgraphId(createUuidv4())).toBe(true)
+    })
+
+    it('returns false for an invalid value', () => {
+      expect(isUuidShapedSubgraphId('not-a-uuid')).toBe(false)
+      expect(isUuidShapedSubgraphId(undefined)).toBe(false)
+      expect(isUuidShapedSubgraphId(42)).toBe(false)
+    })
+  })
+})

src/schemas/subgraphIdSchema.ts

@@ -0,0 +1,10 @@
+import { z } from 'zod'
+
+/** Hash values from the URL bar are untrusted; validate before lookup. */
+export const zSubgraphId = z.string().uuid()
+
+type SubgraphId = z.infer<typeof zSubgraphId>
+
+export function isUuidShapedSubgraphId(value: unknown): value is SubgraphId {
+  return zSubgraphId.safeParse(value).success
+}

src/stores/dialogStore.ts

@@ -47,6 +47,11 @@ interface CustomDialogComponentProps {
    * PrimeVue path — use `pt` for that renderer.
    */
   contentClass?: HTMLAttributes['class']
+  /**
+   * Class applied to the Reka-UI `DialogOverlay` element. Ignored on the
+   * PrimeVue path — use `pt.mask` for that renderer.
+   */
+  overlayClass?: HTMLAttributes['class']
 }

 export type DialogComponentProps = Record<string, unknown> &

src/stores/modelToNodeStore.test.ts

@@ -87,7 +87,8 @@ const MOCK_NODE_NAMES = [
   'IPAdapterModelLoader',
   'LS_LoadSegformerModel',
   'LoadNLFModel',
-  'FlashVSRNode'
+  'FlashVSRNode',
+  'LTXICLoRALoaderModelOnly'
 ] as const

 const mockNodeDefsByName = Object.fromEntries(
@@ -307,7 +308,22 @@ describe('useModelToNodeStore', () => {
       )

       const loraProviders = modelToNodeStore.getAllNodeProviders('loras')
-      expect(loraProviders).toHaveLength(2)
+      expect(loraProviders).toHaveLength(3)
+      expect(loraProviders).toEqual(
+        expect.arrayContaining([
+          expect.objectContaining({
+            nodeDef: expect.objectContaining({ name: 'LoraLoader' })
+          }),
+          expect.objectContaining({
+            nodeDef: expect.objectContaining({ name: 'LoraLoaderModelOnly' })
+          }),
+          expect.objectContaining({
+            nodeDef: expect.objectContaining({
+              name: 'LTXICLoRALoaderModelOnly'
+            })
+          })
+        ])
+      )
     })

     it('should return single provider for model type with one node', () => {
@@ -561,6 +577,18 @@ describe('useModelToNodeStore', () => {
       expect(modelToNodeStore.getCategoryForNodeType('')).toBeUndefined()
     })

+    it('maps the IC-LoRA Loader Model Only node to loras so its lora_name dropdown uses the cloud asset browser (FE-838)', () => {
+      const modelToNodeStore = useModelToNodeStore()
+      modelToNodeStore.registerDefaults()
+
+      expect(
+        modelToNodeStore.getCategoryForNodeType('LTXICLoRALoaderModelOnly')
+      ).toBe('loras')
+      expect(
+        modelToNodeStore.getRegisteredNodeTypes()['LTXICLoRALoaderModelOnly']
+      ).toBe('lora_name')
+    })
+
     it('should return first category when node type exists in multiple categories', () => {
       const modelToNodeStore = useModelToNodeStore()


src/stores/subgraphNavigationStore.navigateToHash.test.ts

@@ -0,0 +1,307 @@
+import { createTestingPinia } from '@pinia/testing'
+import { fromPartial } from '@total-typescript/shoehorn'
+import { setActivePinia } from 'pinia'
+import { beforeEach, describe, expect, it, vi } from 'vitest'
+import { nextTick, ref } from 'vue'
+
+import type * as VueRouter from 'vue-router'
+
+import type { LGraph, Subgraph } from '@/lib/litegraph/src/litegraph'
+import type { ComfyWorkflow } from '@/platform/workflow/management/stores/workflowStore'
+import { app } from '@/scripts/app'
+import { useSubgraphNavigationStore } from '@/stores/subgraphNavigationStore'
+
+const ids = vi.hoisted(() => ({
+  root: '00000000-0000-4000-8000-000000000000',
+  validSubgraph: '11111111-1111-4111-8111-111111111111',
+  deletedSubgraph: '22222222-2222-4222-8222-222222222222'
+}))
+
+const workflowStoreState = vi.hoisted(() => ({
+  openWorkflows: [] as unknown[],
+  activeSubgraph: undefined as unknown
+}))
+
+const routerMocks = vi.hoisted(() => ({
+  push: vi.fn().mockResolvedValue(undefined),
+  replace: vi.fn().mockResolvedValue(undefined)
+}))
+
+const routeHashRef = ref('')
+
+vi.mock('vue-router', async (importOriginal) => {
+  const actual = await importOriginal<typeof VueRouter>()
+  return {
+    ...actual,
+    useRouter: () => routerMocks
+  }
+})
+
+vi.mock('@vueuse/router', () => ({
+  useRouteHash: () => routeHashRef
+}))
+
+vi.mock('@/scripts/app', () => {
+  const mockCanvas = {
+    subgraph: null,
+    graph: null,
+    setGraph: vi.fn(),
+    setDirty: vi.fn(),
+    ds: {
+      scale: 1,
+      offset: [0, 0],
+      state: { scale: 1, offset: [0, 0] }
+    }
+  }
+
+  const mockRoot = {
+    id: ids.root,
+    _nodes: [],
+    nodes: [],
+    subgraphs: new Map(),
+    getNodeById: vi.fn()
+  }
+
+  return {
+    app: {
+      graph: mockRoot,
+      rootGraph: mockRoot,
+      canvas: mockCanvas
+    }
+  }
+})
+
+vi.mock('@/renderer/core/canvas/canvasStore', () => ({
+  useCanvasStore: () => ({
+    getCanvas: () => app.canvas,
+    currentGraph: null
+  })
+}))
+
+vi.mock('@/services/litegraphService', () => ({
+  useLitegraphService: () => ({ fitView: vi.fn() })
+}))
+
+vi.mock(
+  '@/renderer/extensions/vueNodes/composables/useSlotElementTracking',
+  () => ({ requestSlotLayoutSyncForAllNodes: vi.fn() })
+)
+
+const workflowServiceMocks = vi.hoisted(() => ({
+  openWorkflow: vi.fn().mockResolvedValue(undefined)
+}))
+
+vi.mock('@/platform/workflow/core/services/workflowService', () => ({
+  useWorkflowService: () => workflowServiceMocks
+}))
+
+vi.mock('@/platform/workflow/management/stores/workflowStore', () => ({
+  useWorkflowStore: () => workflowStoreState
+}))
+
+function makeSubgraph(id: string): Subgraph {
+  return fromPartial<Subgraph>({
+    id,
+    rootGraph: app.rootGraph,
+    _nodes: [],
+    nodes: []
+  })
+}
+
+async function flushHashWatcher() {
+  await nextTick()
+  await Promise.resolve()
+  await nextTick()
+}
+
+describe('useSubgraphNavigationStore - navigateToHash validation', () => {
+  beforeEach(() => {
+    setActivePinia(createTestingPinia({ stubActions: false }))
+    vi.clearAllMocks()
+    app.rootGraph.id = ids.root
+    app.rootGraph.subgraphs.clear()
+    app.canvas.subgraph = undefined
+    app.canvas.graph = app.rootGraph
+    workflowStoreState.openWorkflows = []
+    workflowStoreState.activeSubgraph = undefined
+    routeHashRef.value = ''
+  })
+
+  it('navigates to a valid, existing subgraph hash', async () => {
+    const subgraph = makeSubgraph(ids.validSubgraph)
+    app.rootGraph.subgraphs.set(subgraph.id, subgraph)
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = `#${ids.validSubgraph}`
+    await flushHashWatcher()
+
+    expect(app.canvas.setGraph).toHaveBeenCalledWith(subgraph)
+    expect(routerMocks.replace).not.toHaveBeenCalled()
+  })
+
+  it('redirects to root when hash references a deleted subgraph', async () => {
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = `#${ids.deletedSubgraph}`
+    await vi.waitFor(() =>
+      expect(routerMocks.replace).toHaveBeenCalledWith(`#${app.rootGraph.id}`)
+    )
+  })
+
+  it('redirects to root when hash is malformed (not a UUID)', async () => {
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = '#not-a-valid-uuid'
+    await vi.waitFor(() =>
+      expect(routerMocks.replace).toHaveBeenCalledWith(`#${app.rootGraph.id}`)
+    )
+    expect(app.canvas.setGraph).not.toHaveBeenCalled()
+  })
+
+  it('does not redirect when hash equals a non-UUID root graph id (loaded workflow slug)', async () => {
+    const slugRootId = 'test-missing-models-in-subgraph'
+    app.rootGraph.id = slugRootId
+    app.canvas.graph = fromPartial<LGraph>({ id: slugRootId })
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = `#${slugRootId}`
+    await flushHashWatcher()
+
+    expect(routerMocks.replace).not.toHaveBeenCalled()
+    expect(app.canvas.setGraph).not.toHaveBeenCalled()
+  })
+
+  it('redirects when hash is a non-UUID slug that does not match root', async () => {
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = '#some-other-slug'
+    await vi.waitFor(() =>
+      expect(routerMocks.replace).toHaveBeenCalledWith(`#${app.rootGraph.id}`)
+    )
+  })
+
+  it('does not redirect or re-set graph when hash equals current root graph', async () => {
+    app.canvas.graph = fromPartial<LGraph>({ id: ids.root })
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = `#${ids.root}`
+    await flushHashWatcher()
+
+    expect(app.canvas.setGraph).not.toHaveBeenCalled()
+    expect(routerMocks.replace).not.toHaveBeenCalled()
+  })
+
+  it('does not redirect when transitioning to an empty hash on the root graph', async () => {
+    routeHashRef.value = `#${ids.root}`
+    app.canvas.graph = fromPartial<LGraph>({ id: ids.root })
+    useSubgraphNavigationStore()
+    await flushHashWatcher()
+    routerMocks.replace.mockClear()
+    vi.mocked(app.canvas.setGraph).mockClear()
+
+    routeHashRef.value = ''
+    await flushHashWatcher()
+
+    expect(routerMocks.replace).not.toHaveBeenCalled()
+    expect(app.canvas.setGraph).not.toHaveBeenCalled()
+  })
+
+  it('redirects when canvas still references a deleted subgraph (stale-graph guard)', async () => {
+    app.canvas.graph = makeSubgraph(ids.deletedSubgraph)
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = `#${ids.deletedSubgraph}`
+    await vi.waitFor(() => {
+      expect(routerMocks.replace).toHaveBeenCalledWith(`#${app.rootGraph.id}`)
+      expect(app.canvas.setGraph).toHaveBeenCalledWith(app.rootGraph)
+    })
+  })
+
+  it('recovers canvas to root even if router.replace rejects', async () => {
+    routerMocks.replace.mockRejectedValueOnce(new Error('navigation aborted'))
+    const warnSpy = vi.spyOn(console, 'warn').mockImplementation(() => {})
+    app.canvas.graph = makeSubgraph(ids.deletedSubgraph)
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = `#${ids.deletedSubgraph}`
+    await vi.waitFor(() =>
+      expect(app.canvas.setGraph).toHaveBeenCalledWith(app.rootGraph)
+    )
+    warnSpy.mockRestore()
+  })
+
+  it('redirects when a workflow load resolves but the subgraph is still missing', async () => {
+    const warnSpy = vi.spyOn(console, 'warn').mockImplementation(() => {})
+    workflowStoreState.openWorkflows = [
+      fromPartial<ComfyWorkflow>({
+        path: 'phantom-workflow.json',
+        activeState: {
+          id: ids.deletedSubgraph,
+          definitions: { subgraphs: [] }
+        }
+      })
+    ]
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = `#${ids.deletedSubgraph}`
+    await vi.waitFor(() => {
+      expect(workflowServiceMocks.openWorkflow).toHaveBeenCalled()
+      expect(routerMocks.replace).toHaveBeenCalledWith(`#${app.rootGraph.id}`)
+      expect(warnSpy).toHaveBeenCalledWith(
+        expect.stringContaining('subgraph not found after workflow load')
+      )
+    })
+    warnSpy.mockRestore()
+  })
+
+  it('redirects when openWorkflow rejects during recovery', async () => {
+    const warnSpy = vi.spyOn(console, 'warn').mockImplementation(() => {})
+    workflowServiceMocks.openWorkflow.mockRejectedValueOnce(
+      new Error('load failed')
+    )
+    workflowStoreState.openWorkflows = [
+      fromPartial<ComfyWorkflow>({
+        path: 'broken-workflow.json',
+        activeState: {
+          id: ids.deletedSubgraph,
+          definitions: { subgraphs: [] }
+        }
+      })
+    ]
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = `#${ids.deletedSubgraph}`
+    await vi.waitFor(() => {
+      expect(routerMocks.replace).toHaveBeenCalledWith(`#${app.rootGraph.id}`)
+      expect(warnSpy).toHaveBeenCalledWith(
+        expect.stringContaining('workflow load failed')
+      )
+    })
+    warnSpy.mockRestore()
+  })
+
+  it('routeHash watcher does not re-enter navigateToHash during recovery redirect', async () => {
+    const warnSpy = vi.spyOn(console, 'warn').mockImplementation(() => {})
+    // Simulate the real router replace: trigger the routeHash watcher
+    // exactly the way vue-router does when the URL is replaced.
+    routerMocks.replace.mockImplementation((target) => {
+      const hash = typeof target === 'string' ? target : ''
+      routeHashRef.value = hash
+      return Promise.resolve(undefined)
+    })
+    app.canvas.graph = makeSubgraph(ids.deletedSubgraph)
+    useSubgraphNavigationStore()
+
+    routeHashRef.value = `#${ids.deletedSubgraph}`
+    await vi.waitFor(() => {
+      expect(routerMocks.replace).toHaveBeenCalledWith(`#${app.rootGraph.id}`)
+    })
+
+    // navigateToHash for the deleted id ran once and produced exactly one
+    // redirect. The watcher must NOT have fired again for the rewritten
+    // (root) hash and produced a second redirect.
+    expect(routerMocks.replace).toHaveBeenCalledTimes(1)
+    expect(app.canvas.setGraph).toHaveBeenCalledWith(app.rootGraph)
+    warnSpy.mockRestore()
+  })
+})

src/stores/subgraphNavigationStore.ts

@@ -2,7 +2,11 @@ import QuickLRU from '@alloc/quick-lru'
 import { useRouteHash } from '@vueuse/router'
 import { defineStore } from 'pinia'
 import { computed, ref, shallowRef, watch } from 'vue'
-import { useRouter } from 'vue-router'
+import {
+  NavigationFailureType,
+  isNavigationFailure,
+  useRouter
+} from 'vue-router'

 import type { DragAndScaleState } from '@/lib/litegraph/src/DragAndScale'
 import type { Subgraph } from '@/lib/litegraph/src/litegraph'
@@ -10,6 +14,7 @@ import { useWorkflowStore } from '@/platform/workflow/management/stores/workflow
 import { useWorkflowService } from '@/platform/workflow/core/services/workflowService'
 import { useCanvasStore } from '@/renderer/core/canvas/canvasStore'
 import { requestSlotLayoutSyncForAllNodes } from '@/renderer/extensions/vueNodes/composables/useSlotElementTracking'
+import { isUuidShapedSubgraphId } from '@/schemas/subgraphIdSchema'
 import { app } from '@/scripts/app'
 import { useLitegraphService } from '@/services/litegraphService'
 import { findSubgraphPathById } from '@/utils/graphTraversalUtil'
@@ -200,20 +205,64 @@ export const useSubgraphNavigationStore = defineStore(
       { flush: 'sync' }
     )

-    //Allow navigation with forward/back buttons
-    let blockHashUpdate = false
+    // Counter so nested/overlapping async navigations don't release
+    // suppression early; gates both the canvasStore.currentGraph watcher
+    // (updateHash) and the routeHash watcher to prevent re-entrant
+    // navigateToHash calls during router.replace().
+    let blockNavDepth = 0
     let initialLoad = true

+    async function withNavBlocked<T>(op: () => Promise<T>): Promise<T> {
+      blockNavDepth++
+      try {
+        return await op()
+      } finally {
+        blockNavDepth--
+      }
+    }
+
+    function ensureCanvasOnRoot() {
+      const root = app.rootGraph
+      const canvas = canvasStore.getCanvas()
+      if (!root || !canvas) return
+      if (canvas.graph?.id !== root.id) canvas.setGraph(root)
+    }
+
+    async function redirectToRoot(reason: string) {
+      const root = app.rootGraph
+      console.warn(`[subgraphNavigation] ${reason}; redirecting to root graph`)
+      try {
+        await withNavBlocked(() => router.replace('#' + root.id))
+      } catch (err) {
+        if (
+          !isNavigationFailure(err, NavigationFailureType.duplicated) &&
+          !isNavigationFailure(err, NavigationFailureType.cancelled)
+        ) {
+          console.warn(
+            '[subgraphNavigation] router.replace rejected during recovery',
+            err
+          )
+        }
+      } finally {
+        ensureCanvasOnRoot()
+      }
+    }
+
     async function navigateToHash(newHash: string) {
       const root = app.rootGraph
       const locatorId = newHash?.slice(1) || root.id
       const canvas = canvasStore.getCanvas()
-      if (canvas.graph?.id === locatorId) return
-      const targetGraph =
-        (locatorId || root.id) !== root.id
+
+      const isRoot = locatorId === root.id
+      const targetGraph = isRoot
+        ? root
+        : isUuidShapedSubgraphId(locatorId)
           ? root.subgraphs.get(locatorId)
-          : root
-      if (targetGraph) return canvas.setGraph(targetGraph)
+          : undefined
+      if (targetGraph) {
+        if (canvas.graph?.id === targetGraph.id) return
+        return canvas.setGraph(targetGraph)
+      }

       //Search all open workflows
       for (const workflow of workflowStore.openWorkflows) {
@@ -222,29 +271,48 @@ export const useSubgraphNavigationStore = defineStore(
         const subgraphs = activeState.definitions?.subgraphs ?? []
         for (const graph of [activeState, ...subgraphs]) {
           if (graph.id !== locatorId) continue
-          //This will trigger a navigation, which can break forward history
+          // This will trigger a navigation, which can break forward history.
+          // After openWorkflow resolves, app.rootGraph has been swapped, so we
+          // intentionally re-read app.rootGraph below instead of using the
+          // `root` captured at function entry.
           try {
-            blockHashUpdate = true
-            await useWorkflowService().openWorkflow(workflow)
-          } finally {
-            blockHashUpdate = false
+            await withNavBlocked(() =>
+              useWorkflowService().openWorkflow(workflow)
+            )
+          } catch (err) {
+            console.warn(
+              '[subgraphNavigation] openWorkflow rejected during recovery',
+              err
+            )
+            return redirectToRoot('workflow load failed')
           }
-          const targetGraph =
+          const loadedGraph =
             app.rootGraph.id === locatorId
               ? app.rootGraph
               : app.rootGraph.subgraphs.get(locatorId)
-          if (!targetGraph) {
-            console.error('subgraph poofed after load?')
-            return
+          if (!loadedGraph) {
+            return redirectToRoot('subgraph not found after workflow load')
           }
+          if (canvas.graph?.id === loadedGraph.id) return
+          return canvas.setGraph(loadedGraph)
+        }
+      }

-          return canvas.setGraph(targetGraph)
+      await redirectToRoot(`subgraph not found: ${locatorId}`)
+    }
+
+    async function safeRouterCall(op: () => Promise<unknown>, label: string) {
+      try {
+        await op()
+      } catch (err) {
+        if (!isNavigationFailure(err, NavigationFailureType.duplicated)) {
+          console.warn(`[subgraphNavigation] ${label} rejected`, err)
         }
       }
     }

     async function updateHash() {
-      if (blockHashUpdate) return
+      if (blockNavDepth > 0) return
       if (initialLoad) {
         initialLoad = false
         if (!routeHash.value) return
@@ -255,16 +323,22 @@ export const useSubgraphNavigationStore = defineStore(
       }

       const newId = canvasStore.getCanvas().graph?.id ?? ''
-      if (!routeHash.value) await router.replace('#' + app.rootGraph.id)
+      if (!routeHash.value) {
+        await safeRouterCall(
+          () => router.replace('#' + app.rootGraph.id),
+          'router.replace'
+        )
+      }
       const currentId = routeHash.value?.slice(1)
       if (!newId || newId === currentId) return

-      await router.push('#' + newId)
+      await safeRouterCall(() => router.push('#' + newId), 'router.push')
     }
-    //update navigation hash
-    //NOTE: Doesn't apply on workflow load
     watch(() => canvasStore.currentGraph, updateHash)
-    watch(routeHash, () => navigateToHash(String(routeHash.value)))
+    watch(routeHash, () => {
+      if (blockNavDepth > 0) return
+      void navigateToHash(String(routeHash.value))
+    })

     /** Save the current viewport for the active graph/workflow. Called by
      *  workflowService.beforeLoadNewGraph() before the canvas is overwritten. */
